2MP Network IR Wedge Camera - 30Mtr.
cctv-system

2MP Network IR Wedge Camera - 30Mtr.
Specifications
Sensor Resolution Mp 2
Camera Type Wedge
Image Sensor 1/2.8” 2MP PS CMOS Image Sensor (0.9071 centimeter)
Minimum Illumination 0.006 Lux@F1.6(Color,30IRE), 0.0006 Lux@F1.6(B/W,30IRE), 0 lux (IR on)
Effective Pixels 1920(H) × 1080(V)
Shutter Speed Auto/Manual 1/3 s–1/100000 s
Angle Adjustment Pan: -30°- 30°, Tilt: 0°- 80°, Rotation: 0°- 360°
RAM 512 MB
Rom 128 MB
Lens 2.8mm fixed lens (3.6mm optional)
Lens Type Fixed-focal
Iris Type Fixed
Max Aperture F1.6
Lens Mount M12
Close Focus Distance 0.8 Mtr.
Backlight Compensation BLC/ HLC/ WDR(120 dB)
Angle Of View 2.8mm: Horizontal: 107°, Vertical: 57°, Diagonal: 128°; 3.6mm: Horizontal: 87°, Vertical: 44°, Diagonal: 105°
Ir Number 2 IR Light
Ir Distance 30 Mtr.
Sn Ratio > 56 dB
Video Compression Instastream, H.265, H.264, H.264H, H.264B, MJPEG (only supported by the sub stream)
Bit Rate Control CBR/ VBR
Bit Rate H.265: 3 kbps–6144 kbps, H.264: 3 kbps–6144 kbps
Day Night Auto(ICR)/Color/B/W
Resolution 2MP (1920 × 1080), 1.3M (1280 × 960), 1MP (1280 × 720), D1, VGA, CIF
Noise Reduction 3D NR/ 2D NR
Image Stabilization Electronic Image Stabilization (EIS)
Motion Detection OFF/ON (4 areas, Rectangular)
Privacy Mask 4 Areas
Roi Support (4 Areas)
Audio Built in Mic
Protocol IPv4, IPv6, HTTP, HTTPS, TCP, UDP, RTP, RTSP, RTCP, RTMP, SMTP V3, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NAS, PPPoE, SNMP, Auto Connect, TLS v1.2 and v1.3, ONVIF (Profile S, Profile G, Profile T), InstaOn
Stream Capability Quad Stream
Ethernet 1 (Built-in M12 port, RJ-45 optional), 10 M/100 M
Storage SFTP, NAS, Micro SD card (max. 512 GB)
Power M12 port PoE (802.3af); RJ45 DC 12V and PoE (802.3af)
Power Consumption Basic: 3.6 W (PoE); Max.: 8.2 W (PoE)
Operating Temperature –30°C to +60°C
Operating Humidity ≤95% RH, non-condensing
Weatherproof Standard IP67, IK10
Dimension 64.8mm × 111.0mm
Casing Metal
Weight 450g
Certificates MTBF Certificate from STQC, IEC 61373, IEC 60571 and IEC 60068-2-10, IEC 50155, EN50121 4:2016, EN61000-4-3:2010, EN 50155, ISO9001, CE, FCC and RoHS, BIS, STQC approved compliance report

The 2MP Network IR Wedge Camera - 30Mtr. (model CP-UNC-WE21L3C-MDS-Q) is a 2MP network camera from CP PLUS in the wedge form factor.

What to consider

As a buyer, focus on the imaging hardware, lens and night coverage, plus networking, storage, audio and environmental protection. Check the specification table above to match the camera to the scene, mounting location and recording system you need.

Platform notes

  • Connects over the network and needs a compatible NVR or recording software; match the number of NVR channels to the number of cameras.
  • Higher resolution means more bandwidth and storage, so size the NVR disks accordingly.
  • Supports ONVIF (Profiles S, G and T), which helps with third-party recorder compatibility; confirm the exact setup before finalising a purchase or quote.
  • Power: M12 port PoE (802.3af); RJ45 DC 12V and PoE (802.3af); consumption Basic: 3.6 W (PoE); Max.: 8.2 W (PoE).

Good fit for

  • Compact mounting spots where a low, angled housing is needed.
  • Transport and rolling-stock style installs, given the railway-related certifications listed.

Not ideal for

  • Sites that need to change the zoom after installation, because the lens is fixed.
  • Sites with no PoE switch or NVR PoE ports, unless a separate power supply is arranged.

Figures are indicative.
